SensL products address the needs of a wide range of applications that use low-light detection.

Sliding Panels Template | CodyHouse
  • Medical Imaging

    Leading coincidence resolving time for best-in-class ToF-PET Performance.

    New and innovative treatments that are targeted at the molecular level within the body are revolutionizing our understanding of, and approach to a range of diseases and conditions. By replacing aging vacuum tubes with SiPM sensors, increased performance and practicality are available at a lower cost.

  • Hazard & Threat

    Excellent energy resolution for rapid isotope identification.

    Hazard and threat detection refers to a broad range of applications that aim to secure national infrastructure against nuclear incidents and contraband trafficking by the screening of cargo, vehicles, baggage and personnel using portal monitors at key entry/exit points.

  • 3D Ranging and Sensing

    High responsivity red sensors for full daylight operation.

    LiDAR is a ranging technique that is increasingly being employed in applications such as mobile range finding, automotive ADAS (Advanced Driver Assistance Systems), gesture recognition and 3D mapping.

  • Biophotonics & Sciences

    Leading coincidence resolving time for best-in-class ToF-PET Performance.

    New and innovative treatments that are targeted at the molecular level within the body are revolutionizing our understanding of, and approach to a range of diseases and conditions. By replacing aging vacuum tubes with SiPM sensors, increased performance and practicality are available at a lower cost.

  • High Energy Physics

    Industry-leading packaging for magnetic and radiopure environments.

    High energy physics (HEP) is at the leading edge of the exploration the fundamental constituents of matter and energy, the interactions and relationships between them, and the nature of space and time.

C_series SiPM Family
C-Series SiPM Family
High volume, low noise, MLP package.

SensL’s C-Series sensors feature industry-leading low dark count rates of 30kHz/mm2 typical, in combination with exceptional breakdown voltage uniformity of ±250mV. The high PDE extends far into the blue part of the spectrum using a high-volume, P-on-N silicon process.

Learn More
C-Series HighlightsTypical Value
PDE @ 420nm42%
Typical dark count 30kHz/mm2
Operating Voltage<30V
Package Type MLP (reflow solder compatible SMT)
Tape & Reel Yes
J_series SiPM Family
J-Series SiPM Family
High-Density Fill Factor Silicon Photomultipliers

SensL’s J-Series sensors have been optimized for high-performance timing applications, such as ToF-PET. They feature industry-leading low dark count rates of 50kHz/mm2, in combination with exceptional breakdown voltage uniformity of ±250mV.

Learn More
J-Series HighlightsTypical Value
PDE @ 420nm50%
Array Fill Factor>90%
Recovery Time (RC)45ns
Package Type TSV (reflow solderable SMT)
Tape & Reel Yes
R-Series SiPM Family
High responsivity, red sensitive, MLP package.

The R-Series is a new family of Silicon Photomultiplier (SiPM) sensors providing sensitivity into the red and NIR portion of the spectrum. The R-Series SiPM sensors feature high responsivity, fast signal response, and a low temperature coefficient, all achieved at a low operating voltage.

Learn More
RA-Series HighlightsTypical Value
Responsivity @ 905nm>100 kA/W
Operating voltage<50 V
Microcell recharge time constant13 ns
Package Type MLP (reflow solder compatible SMT)
Tape & Reel Yes
C-Series Store Highlights

ArrayC-60035-4P-BGA

ArrayC-60035-4P-BGA

$165.00

J-Series Store Highlights

ArrayJ-30035-16P-PCB

ArrayJ-30035-16P-PCB

$488.00

R-Series Store Highlights

MicroRA-SMTPA-100XX

MicroRA-SMTPA-100XX

$195.00
